(V2/V3) Spiral Sash Balances With Foot Attachment

(V2/V3) Spiral Sash Balances With Foot Attachment

Made to order and non-refundable. Please allow up to 7 working days for delivery.
Supplied PRE-TENSIONED to the weight range marked on the balance (e.g. 15lb – 18.8lb). A sash within that range should balance with no tensioning.
Always weigh your sash and quote its weight when ordering.
Sold in PAIRS. One pair is sufficient for ONE sash.
Fine adjustment, only if the sash creeps down: turn the adjuster anticlockwise (viewed from underneath) with a key or flat-bladed screwdriver until it clicks. One click per balance, applied equally to both, to a maximum of 2 clicks.
Extra tension cannot be removed. Balances that have been tensioned cannot be returned.
If the sash still creeps after 2 clicks per side, the balances are wrong for the sash. Re-check the weight and order the correct balances.
For timber windows only
Stainless steel spiral rod with dual tension springs in a semi-flexible outer tube
Twin springs give assisted lift and smooth operation, even on heavier sashes. They suit retirement homes, hospitals and nursing homes.
Non-removable white tube supplied as standard. Clip-on tube covers are available in other colours.
Supplied with timber fittings
AL10–AL50 balances require an 18mm groove. AL60–AL90 balances require a 21.5mm groove.
Fitting instructions are available to download.
Keep balances free of plaster, building dust and debris. A few drops of light oil on the spiral rod will improve the action.

Description
Specification
Documents

Price range: £22.96 through £85.00 ex. VAT

Sash Weight

Length

Clear

Description

Made to order and non-refundable. Please allow up to 7 working days for delivery.
Supplied PRE-TENSIONED to the weight range marked on the balance (e.g. 15lb – 18.8lb). A sash within that range should balance with no tensioning.
Always weigh your sash and quote its weight when ordering.
Sold in PAIRS. One pair is sufficient for ONE sash.
Fine adjustment, only if the sash creeps down: turn the adjuster anticlockwise (viewed from underneath) with a key or flat-bladed screwdriver until it clicks. One click per balance, applied equally to both, to a maximum of 2 clicks.
Extra tension cannot be removed. Balances that have been tensioned cannot be returned.
If the sash still creeps after 2 clicks per side, the balances are wrong for the sash. Re-check the weight and order the correct balances.
For timber windows only
Stainless steel spiral rod with dual tension springs in a semi-flexible outer tube
Twin springs give assisted lift and smooth operation, even on heavier sashes. They suit retirement homes, hospitals and nursing homes.
Non-removable white tube supplied as standard. Clip-on tube covers are available in other colours.
Supplied with timber fittings
AL10–AL50 balances require an 18mm groove. AL60–AL90 balances require a 21.5mm groove.
Fitting instructions are available to download.
Keep balances free of plaster, building dust and debris. A few drops of light oil on the spiral rod will improve the action.

Our Terms and Conditions contain important information relating the purchase and appropriate usage of some of our products. Click here to view our terms and conditions.

Additional information

Weight	N/A
Sash Weight	100-104lbs (45.35-47.17kgs), 16 – 23lbs (7.26 – 10.44kgs), 24 – 31lbs (10.89 – 14.07kgs), 32 – 38lbs (14.52 – 17.24kgs), 39 – 45lbs (17.7 – 20.42kgs), 45 – 50lbs (20.42 – 22.68kgs), 51 – 55lbs (23.14 – 24.95kgs), 56 – 60lbs (25.41 – 27.22kgs), 60 – 64lbs (27.22 – 29.03kgs), 65 – 69lbs (29.49 – 31.3kgs), 70 – 74lbs (31.76 – 33.57kgs), 75 – 79lbs (34.02 – 35.84kgs), 8 – 15lbs (3.63 – 6.81kgs), 80 – 84lbs (36.29 – 38.11kgs), 85 – 89lbs (38.56 – 40.37kgs), 90 – 94lbs (40.83 – 42.64kgs), 95 – 99lbs (43.1 – 44.91kgs)
Length	58" (1437mm Long), 59" (1498mm Long), 65" (1651mm Long), 67" (1701mm Long), 7" (177mm Long), 8" (203mm Long), 9" (228mm Long), 10" (254mm Long), 11" (279mm Long), 12" (304mm Long), 13" (330mm Long), 14" (355mm Long), 15" (381mm Long), 16" (406mm Long), 17" (431mm Long), 18" (457mm Long), 19" (482mm Long), 20" (508mm Long), 21" (533mm Long), 22" (558mm Long), 23" (584mm Long), 24" (609mm Long), 25" (635mm Long), 26" (660mm Long), 27" (685mm Long), 28" (711mm Long), 29" (736mm Long), 30" (762mm Long), 31" (787mm Long), 32" (812mm Long), 33" (838mm Long), 34" (863mm Long), 35" (889mm Long), 36" (914mm Long), 37" (939mm Long), 38" (965mm Long), 39" (990mm Long), 40" (1016mm Long), 41" (1041mm Long), 42" (1066mm Long), 43" (1092mm Long), 44" (1117mm Long), 45" (1143mm Long), 46" (1168mm Long), 47" (1193mm Long), 48" (1219mm Long), 49" (1244mm Long), 50" (1270mm Long), 51" (1295mm Long), 52" (1320mm Long), 53" (1346mm Long), 54" (1371mm Long), 55" (1397mm Long)
